LK-SBA Optical Fiber Ladle Baking Infrared Temperature Measurement Device |
Main Features：
●Selected Germany Original High-Precision Optical Fiber Infrared Thermometer
●Patented direct-impact gas cooling method, no additional piping required, and easy installation.
●Dedicated infrared wavelength can penetrate flames and smoke without interference.
●Coaxial laser aiming for easy and accurate positioning of the measured target.
●The panel is equipped with an LCD for displaying baking temperature and ambient conditions, and features a gas pressure alarm.
●Rugged stainless steel protective components, suitable for harsh industrial sites.
●Automatically switches the gas source to save gas energy
|
Main Application Areas：
Suitable for ladle and tundish baking temperature monitoring, hot and cold rolled plate temperature monitoring, and industrial sites with excessively high ambient temperature and harsh conditions.
|
Main Equipment：
6m Optical Fiber Probe, Infrared Thermometer Main Unit, Control Box, Pressure Regulating Valve, Solenoid Valve, Pressure Alarm, High-Temperature Resistant Protective Components, etc. |
| Measurement Parameters |
| Temperature Measurement Range |
| LK - SBA - MB15 - F□ |
300 ℃∼1500 ℃ |
| LK - SBA - MB20 - F□ |
600 ℃∼2000 ℃ |
| Wavelength Range: |
1.0μm/1.6μm |
| Measurement Accuracy： |
±1.0% |
| Repeatability Accuracy： |
±0.3% |
| Response Time： |
4ms |
| Emissivity： |
0.100∼1.099 |
| Optical Resolution： |
| LK - SBA - MB15 - F□ 125:1 |
| LK - SBA - MB20 - F□ 125:1 |
| Electrical Parameters |
| Analog Output： |
4 - 20mA |
| Digital Output： |
RS485 (optional) |
| Output Impedance： |
500Ω (at 24VDC) |
| Laser： |
650nm, Class Ⅱ, maximum power 1mW |
| Power Supply： |
24VDC ± 20% |
| Relay Input： |
1 channel (automatic on/off of air source) |
| General Parameters |
| Fiber Length： |
6m (standard configuration), 8m, 12m (customization required) |
| Ambient Temperature： |
-10~300°C (probe); -10~60°C (host) |
| Storage Temperature： |
-20~80°C |
| Relative Humidity： |
10~95%, non-condensing |
| Environmental Rating： |
IP65 (NEMA - 4) |
|
 |
 |
|
