LK-MA Intelligent Multi-channel Wireless Transmission Module |
Main Features：
●Used to realize 1-to-1 and many-to-many "acquisition-restoration" of analog quantities.
●No programming required, replaces wired transmission, and is plug-and-play.
●Strong anti-interference capability, suitable for signal transmission in harsh environments.
●3000-meter transmission distance (without obstruction), extremely low power consumption (approximately 0.5W)
●Can operate in the public frequency band, no need to apply for a frequency use license.
●Can connect to devices such as PLC, industrial computer, laptop, and single-chip microcomputer.
|
Main Application Areas：
Industrial Data Acquisition System, Biological Signal Acquisition, Hydrometeorological Monitoring, Control and Processing, Wireless Data Connection, Telemetry Wireless Network, etc.
|
Main Equipment：
Standard Configuration: Transmitting Main Unit, Receiving Main Unit, Antenna, Operation Manual, etc.
Optional Items: PROFIBUS DP/RS485/RS232 Digital Output, etc. |
| Performance Parameters |
| Model： |
LK-MA-DA-I□/0□ |
| Transmission Distance： |
3000m (without obstruction) |
| Transmission Distance： |
3000m (without obstruction) |
| Operating Frequency： |
355 - 570MHz |
| Sensitivity： |
—111—148dBm |
| Communication Protocol： |
Modbus-RTU |
| Transmission Delay： |
< 500ms |
| Electrical Parameters |
| Input Signal： |
4 - 20 mA (8 - channel single - ended analog signal) |
| Output Signal： |
4 - 20 mA (8 - channel single - ended analog signal) |
| Power Supply Requirement： |
220VAC or 24VDC |
| Power Consumption： |
Less than 500mW |
| Antenna Specification: |
Suction cup antenna, SMA standard interface |
| General Parameters |
| Material: |
Aluminum Alloy |
| Dimension: |
240 (L)*160(W)*100 (H) mm |
| Installation Method: |
Four-corner positioning hole installation |
| Ambient Temperature: |
-10 - 70°C |
| Operating Ambient Temperature: |
0°C - 50°C |
| Vibration Resistance Class: |
EN 60947-5-2 |
| Relative Humidity: |
10% - 90%RH, no condensation |
| Weight: |
Approximately 2Kg |
|
 |
 |
|
