LK-RD80 Series Frequency-Modulated Continuous Wave (FMCW) Radar Level Transmitter |
Main Features：
●It can still maintain high measurement accuracy and reliability even under extremely harsh working conditions such as heavy dust and steam, making it suitable for use as a high-precision dosimeter for measurement.
●Rich echo processing algorithms and empirical data for various working conditions and environments
●The measurement range can reach 120 meters, making it suitable for the measurement of extra-large storage tanks.
●The minimum beam angle is 3°, making it suitable for narrow spaces or guided wave pipelines
●It supports standard HART and RS485/MODBUS bus protocols
●Analog output includes 4-20mA current output or wireless transmission
●It supports operation methods such as upper computer configuration software and on-tank display meters
|
Main Application Fields：
It is used in all on-site locations requiring level measurement, such as silos, storage tanks, cyclone wells, ladles, hot metal ladles, etc.
|
Standard Packaging：
Standard Configuration: Main Unit, Adjustable Universal Flange, Operation Manual
Optional Items: PROFIBUS DP Digital Output, Analog Signal Wireless Transmission, etc. |
| Measurement Parameters |
| Model: |
LK-RD8030 |
| Measurement Range: |
0.08 - 120m (segmented) |
| Dielectric Constant: |
>=2 |
| Measurement Accuracy: |
±1mm |
| Beam Angle: |
3°/8°/20° |
| Measurement Frequency: |
76GHz - 81GHz |
| Response Time: |
100ms |
| Electrical Parameters |
| Analog Output: |
4 - 20 mA (2-wire / 4-wire system) |
| Digital Output: |
RS485 / MODBUS Bus / HART |
| Power Supply: |
12 - 28 VDC |
| On-site Operation: |
128*64 Dot Matrix Display / 4 Buttons |
| |
(Upper Computer Configuration Software is Optional) |
| General Parameters |
| Housing Material: |
Aluminum Alloy, Stainless Steel |
| Dimensions: |
∅100*270 [mm] |
| Weight: |
2.5 Kg |
| Protection Class: |
IP67 |
| Vibration Resistance Class： |
EN 60947-5-2 |
| Operating Temperature： |
-20℃~+60℃ |
| Storage Temperature： |
-40℃~+85℃ |
| Interface： |
Output Cable |
|
 |
 |
|
